Horizon

2018/Academic Project

Architectural Design Studio 3

Duration: 8 Weeks

Horizon was fixated on program and functionality. The process of creating this site’s program differed from the normal process, due to the addition of horses to the design process. The concept revolves around having two types of circulation: one that includes horses and humans interacting simultaneously; and the other is elevated above, strictly for humans. This further separated work and observation of the facility. The functionality of the site played a big role in the design process. Creating an easy way for clients to drop off their horses without being forced to walk a long way after parking was essential. To solve this problem, every stall has an opening towards the parking area for quick and easy drop off. The use of butterfly and slanted roofs were a design solution geared towards the hot air circulation generated by the forging and shoeing area where temperatures remain above 100 degrees.

Model Photos

Model photos depicting a flat site with little vegetation, and elevation change.

Elevations & Sections

01. Southwest Elevation

02. Northwest Elevation

03. Horse Stable Section

04. Courtyard Section

Renderings

Renderings above depicting space qualities.

Floor Plan

Site Plan

The site is located on a large field in Norman, Oklahoma. The terrain is almost completely flat, helping with the functionality of the design. The site contributes to an accessible structure, but also causes design challenges of integrating the facility into the landscape.

Materials

The material palette is aimed towards an industrial feel.
